Spec Warranty – Residential – Mower 3 years Warranty – Residential – Engine 3 years Warranty – Commercial – Mower 30 days Warranty – Commercial – Engine 90 days Air Filter Standard Briggs & Stratton Air Cleaner Anti Scalp Wheels 2 Standard Armrests Optional Bagger Capacity 4.9 bushels Blade Design 0.164 in. / 0.417 cm Steel with Blade Stiffner Blade Tip Speed 18,179 ft/min / 5,541 m/min Box Dimensions 82.0 in. x 49.0 in. x 35.0 in. / 208.3 cm x 124.5 cm x 88.9 cm CARB Compliant Not CARB Compliant Caster Tires 11 in. x 4 in. – 5 in. Pneumatic Clutch Electromagnetic Cooling System Air Cooled Crankshaft 1″ (25 mm) w/Steel Protector Cup Holder Standard Cutter System Steel Cutting Blade Deck Design 10-Gauge steel IrongForged® Deck Material 10 Gauge Steel Deck Size 34 in / 86 cm Discharge Chute Side Drive System HYDRO Drive Tires 18 in. x 6 in. – 8 in. (45.7 cm x 15.2 cm – 20.3 cm) Drive Type Rear-Wheel Drive Engine 22 hp Briggs and Stratton EXI 724cc Engine Brand Briggs and Stratton Engine Displacement (cc) 724 cc Engine Horsepower 22.0 hp Engine Power (kW) 16.4 kW Foot Operated Height of Cut Optional Forward Ground/Transport Speed Up to 7.0 mph / 11.2 kph Forward Mowing Speed Up to 7.0 mph / 11.2 kph Fuel Capacity 3 gal. / 11.4 L / 12 Qt. Fuel Type Gasoline Greasable Bearings Yes Height of Cut 1.5 – 4.5 in. / 3.8 – 11.4 cm Hitch Bracket Standard Hour Meter Optional Hydraulic Dampeners Yes, Non-Cavitating Hydraulic Drive Standard Number of Blades 2 Product Type TimeCutter Product Use Residential Recommended Oil Type 10W-30 Roll-Over Protection System (ROPS) Optional Seat 16″ Handcrafted Spindle Bearings Maintenance-free Spindle Housing Cast-Aluminum Start Type Electric Steering Controls Dual Wrap Around Levers Steering Dampeners Standard Dampers Terrain Type Flat with Obstacles Tow Capacity Combined machine, user, towed weight may not exceed 1,000 lbs. Transmission Dual Hydrostatic HG-EZT2100 Washout Port Standard Weight 496 lbs / 225 kg
