Standard grease gun-HHFP G 1/8″ -GBDR-MU Item number: 12 632 125 EAN: 4103810127328 Discount group: A Technical data Grease gun connection, pressure-side: G 1/8” Capacity (cm³): 500 Refilling options: 400 g grease cartridge, DIN 1284, or bulk grease using a spatula Diameter of grease piston (mm): 8 Grease pump piston actuation: manually lever operated Delivery rate/stroke (cm³): 1.2 at a grease density of 0.92 kg/dm³, tested with grease cartridge 400 g (12 511) Discharge pressure up to (bar): 400 Burst pressure system (bar): 850 Burst pressure grease gun head (bar): 1200 Operation of push rod: with L-design handle Cover: loose Wall thickness of grease gun tube (mm): 1.0 Lacquering: silver Dimensions LxWxH (mm): 395 x 120 x 66 Weight (kg): 1.25 Specification ● Spout, angled, G 1/8”, 150 mm (12 735) ● Coupler, 4 jaws, G 1/8” (12 731) Special notes ● Operates with greases up to NLGI grade 2 at 20°C ● Plunger with exactly fitting when using bulk grease or cartridge ● acc. to DIN 1283 ● TÜV – certified ● Pump piston with high accuracy of fit to the cylinder (no dummy apparent lubrication) ● Performance unchanged after 40.000 actuating cycles ● Grease gun head, zinc die casting Z 410 ● Sure grip handling due to deep band knurls ● Safe handle on the push rod ● Slip resistant handle on grease gun lever ● Plunger rod clamp on end cap enables manual pressure to be applied to spring to compress bulk grease, or to force in the plunger in damaged cartridges. ● Low effort required for lubrication due to optimum lever efficiency ● High-speed ventilation, by half a rotation of the grease gun tube Packaging Package: Polybag, printed, with EAN bar code Dimensions LxWxH (mm): 400 x 360 x 145 Weight including package (kg): 13.2 Packing unit: 10.0
